Worktable size(mm)

600*460

720*530

CNC axis travel(X×Y)

400*320

500*400

Max. cutting workpiece     thickness(mm)

280

300

Max workpiece weight(kg)

300

500

X、Y、U、V Control motor

X/Y Japan Panasonic Servo Motor U/V Hybrid drive Motor

X/Y Japan Panasonic Servo Motor U/V Hybrid drive Motor

X、Y、Double nut screw,linear guide rail

German IF brand/Taiwan AieTAC brand

German IF brand/Taiwan AieTAC brand

Z-axis control method

Electric lift(One click back to the origin)

Electric lift(One click back to the origin)

Max cutting taper

±10°/80mm(Optional ±15°/80mm)

±10°/80mm(Optional ±15°/80mm)

Wire electrode diameter(mm)

0.1~0.2mm(Standard φ0.18)

0.1~0.2mm(Standard φ0.18)

Cutting accuracy(mm)

≤±0.004 Φ20mm H=40mm (multiple cutting)

≤±0.004 Φ20mm H=40mm (multiple cutting)

Positioning accuracy

≤±0.003mm (L=500mm)

≤±0.003mm (L=500mm)

Surface roughness(μm)

Ra≤0.65

Ra≤0.65

Cutting efficiency(mm²/h)

9000-15000

9000-15000

Working Voltage(V)

Two-phase 220v

Two-phase 220v

Power consumption

≤3Kw

≤3Kw

Tank capacity(L)

150L

150L

Weight(kg)

≈1700

≈1900

Controlled axis

5-axises

5-axises

Control system

Autocut

Autocut

Machine dimension(mm)

≈1750x1100x1950

≈1900x1300x1950

Control cabinet size（mm）

≈1200x650x1850

≈1200x650x1850

Tank size（mm）

≈930x550x700

≈930x550x700

Filter type

 3nd filtration

 3nd filtration

Molybdenum wire tensioning device

√

√

Table waterproof cover

√

√

Aluminum Cutting Device

√

√
