Item | Unit | EDM-CNC450 | EDM-CNC540 | EDM-CNC650 | EDM-CNC850 |
Worktable dimension | mm | 700*400 | 800*500 | 900*500 | 1100*600 |
X/Y Travel | mm | 450*350*300 | 500*400*300 | 650*400*350 | 850*500*400 |
Oil tank dimension | mm | 1010*610*380 | 1300*880*540 | 1600*900*580 | 1800*1000*600 |
Max. electrode weight | kg | 50 | 120 | 150 | 180 |
Max. workpiece weight | kg | 800 | 1800 | 2000 | 3000 |
Max. Distance from electrode to worktable | kg | 700 | 700 | 750 | 900 |
| Max. Liquid level | mm | 300 | 700 | 750 | 900 |
Machine weight | kg | 2200 | 2800 | 3300 | 4500 |
Total power | KVA | 9 | 9 | 9 | 9 |
Machine size | mm | 1400*2100*2300 | 1775*2155*2500 | 2005*2700*2650 | 2265*2970*2900 |
Max. Process current | A | 50 | 50 | 50 | 50 |
Input power | 380V | 380V | 380V | 380V | |
Surface Roughness | μm | Ra 0.1 | Ra 0.1 | Ra 0.1 | Ra 0.1 |
Min. electrode loss | % | 0.1 | 0.1 | 0.1 | 0.1 |
Max. output | mm3/min | 500 | 500 | 500 | 500 |
Standard process | Copper/steel, micro copper/steel, graphite/steel, copper tungsten/steel, micro copper tungsten/steel, steel/steel, copper tungsten/hard alloy, copper/aluminum, graphite/titanium, etc | Copper/steel, micro copper/steel, graphite/steel, copper tungsten/steel, micro copper tungsten/steel, steel/steel, copper tungsten/hard alloy, copper/aluminum, graphite/titanium, etc | Copper/steel, micro copper/steel, graphite/steel, copper tungsten/steel, micro copper tungsten/steel, steel/steel, copper tungsten/hard alloy, copper/aluminum, graphite/titanium, etc | Copper/steel, micro copper/steel, graphite/steel, copper tungsten/steel, micro copper tungste n/steel, steel/steel, copper tungsten/hard alloy, copper/aluminum, graphite/titanium, etc | |
Interpolate | Straight line, arc, spiral line | Straight line, arc, spiral line | Straight line, arc, spiral line | Straight line, arc, spiral line | |
Compensation for each axis | Perform step error compensation and gap compensation for each axis separately | Perform step error compensation and gap compensation for each axis separately | Perform step error compensation and gap compensation for each axis separately | Perform step error compensation and gap compensation for each axis separately | |
Max. Axis No. | 3-axis link (Standard)4- axis link (Optional) | 3-axis link (Standard)4- axis link (Optional) | 3-axis link (Standard)4-axis link (Optional) | 3-axis link (Standard)4- axis link (Optional) | |
Resolution | µm | 0.4 | 0.4 | 0.4 | 0.4 |
Oil tank open type | Door open up&down | Door open up&down | Door open up&down | Door open up&down | |
Min. Control unit | µm | 1 | 1 | 1 | 1 |
Input type | LCD/Keyboard | LCD/Keyboard | LCD/Keyboard | LCD/Keyboard | |
Display | 15〞TFT-LCD | 15〞TFT-LCD | 15〞TFT-LCD | 15〞TFT-LCD | |
Manual control box | Standard Jog (muti-switch） Auxiliary A0-A3 | Standard Jog (muti-switch） Auxiliary A0-A3 | Standard Jog (muti-switch） Auxiliary A0-A3 | Standard Jog (muti-switch） Auxiliary A0-A3 | |
Position instruction | Absolute/Incremental | Absolute/Incremental | Absolute/Incremental | Absolute/Incremental | |
Input scope | mm | +9999.999-9999.999 | +9999.999-9999.999 | +9999.999-9999.999 | +9999.999-9999.999 |
Stored program of discharge process | 1000 sets (C000-C999) | 1000 sets (C000-C999) | 1000 sets (C000-C999) | 1000 sets (C000-C999) | |
Stored program of dias process | 1000 sets (H000-H999) | 1000 sets (H000-H999) | 1000 sets (H000-H999) | 1000 sets (H000-H999) | |
Subprogram nested level | 50 | 50 | 50 | 50 | |
Q instruction insertion times | 8 | 8 | 8 | 8 | |
Coordinate No. | 60 | 60 | 60 | 60 | |
Drive type | AC servo | AC servo | AC servo | AC servo | |
Control cabinet weight | kg | 300 | 300 | 300 | 300 |
Control cabinet size | mm | 1700*620*1880 | 1700*620*1880 | 1700*620*1880 | 1700*620*1880 |
Question: Are you a manufacturer or a distributor?
Answer: We are manufacturers. Welcome to visit our factory.
Question: How to choose the machine I want?
Answer: First of all, please match the worktable stroke and cutting thickness according to the size of the workpiece to find the appropriate model. Secondly please check whether the accuracy and roughness meet your requirements.
Question: The voltage in our country is three-phase 220V (or single-phase 220V, or other voltages), and the voltage of the machine is three-phase 380V. Can you change the voltage?
Answer: Yes. Please tell me the voltage you need and we will change it.
Question: If I purchase your machine, how can I obtain technical support?
Answer: We have detailed teaching videos. Even beginners can operate by watching the videos. Please search "Miyang Machine" on Facebook. Watch more videos!
Question: How is the after-sales service?
Answer: Damaged parts will be replaced free of charge during the warranty period. After the warranty period, they will be replaced at cost price. If you have any questions we will quickly provide you with solutions by shooting videos or other means.
